ZGT Optical Comm LimitedAbout Usno.A401, 1 jour plus tard, immeuble, parc électronique de la station ying, communauté de longue journée, rue de longue journée, district de pingshan, ville de la ville de She N, province du bâtiment GU case G, Chine.ZGT has been committed in fiber optical connectivity products for 20 years. We design, manufacture for customers all of the world.ZGT has two optical manufacturing plants and a mould & plastic injection factory located in Shenzhen China and Henan China, with 400 employees and 7000m2 clean workshop for adaptors, patch cords, MPO and attenuators. With monthly capacity of 3 million pcs of adaptors, 1 million of connectors, 1 million of patch cords, 20 thousands of MTP terminals and 20 thousands
Competitive Advantage:
Telcordia GR-326, IEC, TIA/EIA Standard compliant
100% Optical performance inspection and end-face geometric
Low Insertion Loss.
RoHS Compliance
Customized design and production.
Information：
Mode | SM |
MM | |
End Face | PC |
APC | |
Ferrule ID (μm) | 125.3, 125.5, 126, 127 |
Cable Diameter | 0.9mm ,2.0mm ,3.0mm |
Boot Color | Blue, Green, Beige, Red, Black |
Fiber counts | SX and DX |
| Specifications | |||||
| SM | MM | ||||
| 9/125 | 50/125 | 62.5/125 | OM3/OM4 | ||
| UPC | APC | PC | |||
| Attenuation | From 1dB to 30dB | ||||
| Tolerance | ±0.5dB(1～10dB), ±10%dB(11～30dB) | ||||
| Durability | 1000 times | ||||
| Working Tem | -40 to +80℃ | ||||
| Storage Tem | -40 to +80℃ | ||||
| Endface Geometry | |||||
| Parameter | 2.5μm Ferrule | 1.25μm Ferrule | |||
| UPC | APC | UPC | APC | ||
| Radius of Curvature | 10-25mm | 5-12mm | 7-25mm | 5-12mm | |
| Apex Offset | 0~50μm | 0~50μm | 0~50μm | 0~50μm | |
| Fiber Height | -100~50nm | -100~100nm | -100~50nm | -100~100nm | |
| Angle | 7.7-8.3 degree | 7.7-8.3 degree | |||
| 3D Geometry |         | ||||
