Type

1×2

1×4

1×8

1×16

1×32

1×64

2×2

2×4

2×8

2×16

2×32

2×64

Fiber Type

9/125 um or customer appointed

Operating Wavelength(nm)

1260~1650

Insertion Loss(dB)

Typical

3.6

6.8

10.0

13.0

16.0

19.5

4.0

7.0

10.5

13.5

16.5

20.5

(P/S)Max

3.8/
4.0

7.1/
7.3

10.2/
10.5

13.5/
13.7

16.5/
16.8

20.5/
21.0

4.1/
4.3

7.4/
7.6

10.8/
11.0

14.3/
14.5

17.3/
17.5

20.7/
21.5

Loss Uniformity(dB)-Max

0.6

0.6

0.8

1.2

1.5

2.5

0.8

0.8

1.5

2.0

2.5

2.5

Polariation

Dependent Loss(dB)-Max

0.15

0.15

0.25

0.3

0.3

0.3

0.2

0.2

0.3

0.4

0.4

0.4

Dimension(WxHxL)(mm)

Ribbon/Bare Fiber

4×4
×40

4×4
×40

4×4
×40

4x7
x50

4x7
x50

4x12
x60

4×4
×50

4×4
×50

4×4
×50

4x7
x60

4x7
x60

4x12
x60

Dimension(WxHxL)(mm)

ABS BOX(0.9, 2.0, 3.0mm)

100x
80x10

120x80x18

141x114x18

100x80x10

120x80x18

141x114x18

Directivity(dB)-Min

55

Return Loss(dB)-Min

UPC:50  APC:60

Operating Temperature(℃)

-40~85

Storage Temperature(℃)

-40~85

Connector type

FC, SC.ST, LC, MU…..
