Material:
Ferrule: Zirconia
Fibers: Corning, Draka, YOFC
Jacket: PVC, LSZH, OFNR, OFNP
Cable: Tight buffer, easy stripping tight buffer, loose tube
Competitive Advantage:
Telcordia GR-326, IEC, TIA/EIA Standard compliant
100% Optical performance inspection and end-face geometric
Low Insertion Loss and high Return Loss
Varieties of Cable Assemblies
RoHS Compliance
| Specifications | |||||
| SM | MM | ||||
| 9/125 | 50/125 | 62.5/125 | OM3/OM4 | ||
| UPC | APC | PC | |||
| Attenuation | From 1dB to 30dB | ||||
| Tolerance | ±0.5dB(1～10dB), ±10%dB(11～30dB) | ||||
| Durability | 1000 times | ||||
| Working Tem | -40 to +80℃ | ||||
| Storage Tem | -40 to +80℃ | ||||
| Endface Geometry | |||||
| Parameter | 2.5μm Ferrule | 1.25μm Ferrule | |||
| UPC | APC | UPC | APC | ||
| Radius of Curvature | 10-25mm | 5-12mm | 7-25mm | 5-12mm | |
| Apex Offset | 0~50μm | 0~50μm | 0~50μm | 0~50μm | |
| Fiber Height | -100~50nm | -100~100nm | -100~50nm | -100~100nm | |
| Angle | 7.7-8.3 degree | 7.7-8.3 degree | |||
| 3D Geometry |         | ||||
